Grease Trap

1000 Grease Trap

Dig Pit Roughly 7.5'x8'
Size Including Lid (WxLxH) 76"x90"x73"
Weight 15,500 lbs
54.75" to Inlet Flow Line from Tank Bottom
52.5" to Outlet Flow Line from Tank Bottom

1500 Grease Trap

Dig Pit Roughly 7.5'x13'
Size Including Lid (WxLxH) 76"x128"x73"
Weight 21,000 lbs
6" at 53.75" to Inlet Flow Line from Tank Bottom
4" at 55" to Inlet Flow Line from Tank Bottom
6" at 51" to Outlet Flow Line from Tank Bottom
4" at 52.75" to Outlet Flow Line from Tank Bottom

2000 Grease Trap

Dig Pit Roughly 7.5'x15'
Size Including Lid (WxLxH) 76"x171"x73"
Weight 28,900 lbs
6" at 53.75" to Inlet Flow Line from Tank Bottom
4" at 55" to Inlet Flow Line from Tank Bottom
6" at 51" to Outlet Flow Line from Tank Bottom
4" at 52.75" to Outlet Flow Line from Tank Bottom
